PUDU D5 Security Robot for Complex Terrains

The PUDU D5 is designed for environments that challenge typical robots - uneven terrain, slopes, stairs, multi-level areas, and harsh weather. It can be deployed for security patrol and escort functions (scheduled routes, perimeter checks, supervised autonomy) while also serving as a mobile carrier for supplies or equipment across large properties.  Included remote control provides direct control of D5 robot as optional non-autonomous use.

Carry Items Across Mixed Terrain

With a 66 lbs. payload capacity, the D5 can transport site supplies, tools, small packages, or mission payloads, helping reduce staff travel time and improving response speed across warehouses, yards, campuses, industrial sites, and remote facilities.

Perception + Mobility for Safer Autonomy

A 360° sensing stack (LiDAR + cameras) supports reliable localization and navigation around dynamic obstacles, while legged mobility helps maintain progress where wheeled robots struggle.

Modular for Mission-Specific Payloads

A modular platform supports add-ons such as cargo modules/delivery crates and inspection payloads, enabling you to tailor the robot to security, logistics, inspection, and research needs.

Real Time Compute

High-performance compute (up to 275 TOPS) enables real-time mapping (SLAM), obstacle avoidance, and autonomous path planning.

Common Use Cases

• Security Patrol: Perimeter sweeps, scheduled routes, site monitoring
• Security Escort: Guided accompaniment across campuses or industrial sites
• Mobile Carrying / Delivery: Moving tools, supplies, parts, or packages across large properties
• Industrial Inspection Routes: Routine checks, perimeter sweeps
• Campus / Large-Site Logistics: Support across mixed terrain
• Remote Site Monitoring: Where indoor robots are impractical

Key Specifications

• Top Speed: Up to 11.2 mph
• Payload capacity: Up to 66.1 lbs.
• Step / Stair Traversal: Continuous 9.8 in stairs/steps
• Slope Capability: 30° (~57.7% grade)
• Estimated Single-Charge Range: Up to 8.7 miles
• Environmental Rating: IP67
• Operating Temperature: –4°F to 131°F
• Cold Start: 14°F
• Compute: Up to 275 TOPS
• Perception: Dual 192-line LiDAR + fisheye cameras

Model options

• PUDU D5: Legged version for maximum terrain adaptability
• PUDU D5-W: Wheeled variant optimized for mixed surfaces (where applicable)

Accessories / Add-ons (Optional)

• Cargo/delivery crate (for item transport)
• Inspection payload / gimbal options
• Charging station / dock

Note: Performance figures (range, speed, runtime, traversal) are typically based on controlled testing and can vary with payload, terrain, temperature, and site conditions. Product features and configurations may vary by region and production version.

Specs

Robot and Chassis

• Dimensions:
• Weight: 66 pounds

Battery and Power

• Battery Capacity: 1.0 kWh (1000 Wh) onboard battery
• Runtime about 2.5 - 3.0 hours per charge based on continuous operation

• 2 Hour charging time with fast charge charing station


In the Box

• Pudu D5 Robot

• D5 Remote Control for optional non-autonomous use
• User manual and quick-start guide
• Charging cord 110v
• Note: Charging Station also available, sold separately

Media

FAQs

Q1. What types of facilities is the PUDU D5 best suited for?
PUDU D5 is built for complex indoor/outdoor and industrial environments where terrain, weather, stairs/steps, and large footprints make traditional robots struggle—think industrial parks, airports, transit hubs, ports, campuses, utilities, and large perimeter sites.

Q2. Is it designed for outdoor use and harsh environments?
Yes. The D5 series is designed for real-world outdoor deployment with IP67 ingress protection, cold-start capability, and an operating temperature range suited for demanding environments.

Q3. How long can it run on a typical shift?
Runtime depends on configuration and load. PUDU D5: ~2 to 2.5 hours operating time PUDU D5-W: ~2 to 3 hours operating time (Battery capacity is listed as 1000 Wh.)

Q4. What kinds of tasks can it perform besides patrol—can it carry items?
Yes. D5 supports modular add-ons (e.g., delivery boxes / crates and inspection payloads), so it can be configured for light logistics / item transport in addition to inspection.
Q5. Can it be used for security and patrol?
Yes. D5 is positioned for security/patrol and perimeter workflows, combining autonomous navigation, remote visibility/control, and modular payload options depending on your site needs.

Q6. Is it safe around people, vehicles, and obstacles?
D5 uses a full-surround perception stack (including dual LiDAR and multiple cameras) to support centimeter-level positioning and robust obstacle detection/avoidance for operation in dynamic environments.

Q7. What’s the difference between PUDU D5 and PUDU D5-W?
They share the same platform approach (autonomy + perception + modularity), but differ in mobility style:

• D5 (legged): Optimized for stronger terrain adaptability
• D5-W (wheel-leg hybrid): Optimized for faster/longer travel on mixed smoother surfaces (while still handling obstacles)

Q8. How does charging work and what infrastructure is required?
D5 supports a Charging Station accessory (dock). The dock is optional / sold separately, and you’ll generally just need standard facility power where the dock is installed. Public specs don’t list an official “full charge time,” so treat that as config-dependent and confirm with the seller.

Q9. How much can it carry?
D5 is rated for 44–66 lbs payload, depending on task and configuration—useful for carrying inspection equipment or a delivery crate/module.

Q10. Can it handle steps, slopes, and uneven terrain?
Yes—this is a core purpose of the platform. Specs call out the ability to handle steps/obstacles and steep descents, supporting use in facilities with ramps, curbs, and mixed terrain.

Q11. How difficult is it to train staff and deploy?
Most deployments focus on: mapping/route setup, defining patrol or transport workflows, and basic operational procedures (start/stop, remote monitoring, and routine checks). D5 also supports voice/gesture interaction and autonomous following, which can simplify day-to-day operations.

Q12. Can it integrate with existing security systems or building infrastructure, and does it support APIs?
D5 supports remote vision/control workflows and is built as a modular platform for real-world operations; integration feasibility depends on your specific security stack (VMS, access control, dispatch, etc.) and the integration method supported by your deployment partner. For API/SDK specifics, confirm the latest integration options in the current product documentation.
